Product Information

Highly equipped with fixed in-ground under vehicle surveillance camera system is a set of automatic detection of the vehicle chassis, and the under  vehicle  image acquisition, display, splicing, capture summary, compare the alarm, automatic loop control as one of the vehicle security system.

The system can effectively prevent  the hidden bombs, weapons, biochemical hazards, dangerous people in and out of government agencies, military management, bank warehouses, stations and terminals and other important security protection places under vehicle;

Preventing the under vehicle of dangerous goods such as drugs and firearms and ammunition, illegal smuggled goods and even suspicious persons from passing through customs and border checkpoints.

Prevent detainees from absconding from prisons, detention centers, drug rehabilitation centers and so on;

At the same time, it can be applied to the chassis of trains, automobiles and other vehicles for traffic safety testing and quality inspection and assessment of vehicle conditions.

Application Scenario：

1. Temporary security prevention and anti-terrorism checks at the entrances and exits of vehicles for large national conferences, games, exhibitions and other events;

2, The temporary entrance and exit of prisons, detention centers, drug rehabilitation centers, etc. to prevent the escape check;

3, Anti-terrorism anti-entrapment inspection of entrances and exits, parking lots of key places such as airports, governments, bank depots, bonded areas, embassies, port terminals, stations, military and public security;

4, Customs, border control ports of the checkpoint temporary anti-smuggling, anti-smuggling checks;

5, Vehicle performance inspection at traffic security checkpoints, vehicle testing centers, 4S store maintenance workshops, new energy exchange stations, etc.

Function Overview:

1, 4 million ultra-high definition complete under vehicle process video or photo recording

2, later can be seamlessly upgraded to under vehicle monitoringsand under vehicle scanning

3、Automatic anti-crushing self-protection lift, can automatically remove sand, dust, rain, snow and other debris;

4, the ground 2CM installation height and two-way gentle slope can be a low barrier to pass the inspected vehicle without impact impact;

5、Intelligent full-view angle underbody complementary lighting and chassis 180-degree panoramic monitoring;

6, Full warning orange eye-catching, can also be all 304 stainless steel finishing, resistance to heavy vehicle crushing 56 tons or more, and can be waterproof IP68 soak in water for 60 hours, configured with a complete temperature control system can be alarmed to linkage cooling, de-fogging anti-condensation;

7, Can be integrated license plate, car number, box number and other identification, and can support multiple brands of undercarriage, license plate and other collection camera access, easy system integration;

8, Can collect the panoramic view of the security check lane and the roof, both sides of the car and the chassis of the multi-channel video, can be intelligently photographed and associated preservation.

9, Can be integrated with the vehicle personnel information and goods security information and related records query; can linkage gates, barricades and other peripheral equipment to work together;

10、Multiple lanes can be integrated and uploaded to the central management platform;

11, can be domestic operating systems, embedded systems running under the environment;

12, support for multi-language interface switching.

Characteristic advantage：

The overall orange eye-catching warning is more compact and exquisite;

Two-way low-obstacle slope protective cover has built-in automatic dust removal, which can resist rolling and self-protection lifting.

The integrated temperature and humidity LCD screen and background software synchronously display temperature and humidity, and automatically control cooling and heating to defog and prevent condensation.

4 million high-definition images can be connected to platform software such as vehicle bottom monitoring and photographing, and the overall modular design is convenient for installation and maintenance.

Can be upgraded to underbody scanning.
