Basic parameter indicators:

Channel size 500 (width) × 300 (height) mm

Conveyor belt speed 0.22m/s (adjustable)

Rated load of conveyor belt 150 kg

Resolution: 0.101 mm diameter metal wire (0.0787 mm diameter metal wire) (0.078 mm diameter metal wire)

Penetration 10 mm steel plate (38 mm steel plate) (40 mm steel plate)

Film safety is safe for ISO1600 film

Leakage dose <0.05μGy/h

X-ray generator:

Ray beam direction bottom-illuminated

Tube current 0.4~0.5mA (adjustable) (0.6~0.8mA adjustable) (0.4~0.5mA adjustable)

Tube voltage 80 KV (adjustable) (125 KV adjustable) (160 KV adjustable)

Beam divergence angle 60°

Cooling/working cycle Sealed oil cooling/100%

Image processing system:

X-ray sensor L-shaped photodiode array detector (single energy) (multiple energy), 12bit depth

High-resolution 17-inch LCD monitor

Color image display 24-bit true color display

Edge enhancement: The contour edges of objects are clearer

Super image enhancement, image details are clearer

High penetration display Improve the contrast of the bright area in the image, making the easy penetration area clearer

Low-penetration display Improve the contrast of dark areas in the image and make difficult-to-penetrate areas clearer

Magnifier partial magnification function

Brighten/Darken Increase the brightness of the image/Reduce the brightness of the darkened image

Image pull back/pull forward Display the first 20 images, and can perform any image processing on the current image

Image restoration: The image display returns to its original state

Image storage Any image can be saved in real time, and any image processing can be performed, and continuous work can be saved

Use environment:

Working temperature/humidity 0℃～45℃／20%～95% (non-condensing)

Storage temperature/humidity -20℃～60℃／20%～95% (non-condensing)

Working voltage 220VAC (±10%)? 50±3HZ

Power loss 1.0KW (maximum)

Noise level <60dB
