Unique global features:

One-key shutdown control When shutting down, you only need to turn the key once, and the equipment will automatically and safely shut down to reduce equipment failure.

Environmental protection design The lead curtain is added with a protective film to prevent guests' hands from contacting lead and avoid lead pollution.

Dynamic screen switching The screen can be switched when it is still, and it can be switched freely when it is dynamic.

Basic parameter indicators:

Channel size 500 (width) × 300 (height) mm

Conveyor belt speed 0.22m/s

Rated load of conveyor belt 150 kg (170 kg)

Penetration is greater than 11mm steel plate (43mm)

Pass rate 720/h

Line resolution: 0.0787mm diameter wire

Penetration resolution 0.127 mm diameter wire

Spatial resolution level: diameter 1.0 mm vertical: diameter 1.0 mm

Film safety is safe for ISO1600 film

Radiation safety:

Single inspection dose is less than 1μGγ

The leaked radiation dose rate is less than 0.3μGγ/h (the test at any place 5cm away from the outer surface of the equipment meets and is better than domestic and foreign health and safety standards)

Efficient radiation protection Double-layer staggered arrangement of wear-resistant and strong lead curtains, and ultra-thick 2-5mm lead plates to block X-ray radiation leakage.

X-ray generator:

Digital interface Tube voltage 80-160KV (adjustable), current 0.3-1.2mA (adjustable)

Cooling/working cycle Sealed oil cooling/100%

Equipment function:

Image processing function color/black and white, local increase, super increase, edge enhancement, gray sweep, high penetration, low penetration, brightening, darkening, zoom in/out, pull back/pull forward (organic removal, inorganic removal, reverse color , False color, organic matter enhancement, suspicious item alarm mark)

System functions Power-on self-check, multi-level user management, image management, TIP management, curve diagnosis, system equipment information, image mirroring, 1-16 (1-64) times stepless zoom, operator training, precise positioning of packaged images, and emptying Channel reminder, device information query, fast language switching, U disk upgrade software, remote real-time viewing of images, one piece of calibration, one-key shutdown, intelligent roller (optional)

Structural design:

The frame incorporates advanced industrial design concepts, anti-rust, anti-corrosion, anti-cable damage, solemn and stable.

Anti-pinch device The unique anti-pinch design under the belt at the entrance and exit of the channel and the receiving rack is safe and reliable.

High-quality belt The surface of the conveyor belt is printed with diamond patterns, which is more resistant to cutting and scratching during use; the thickness of 2mm is more resistant to stretching and not easy to deform; the surface is anti-static, and it is not easy to be polluted during use.

Stereoscopic indicator lights stand on the four corners to display the working status of the equipment in all angles, with a simple and beautiful appearance (optional)

Humanized design Professional keyboard, with ergonomically designed workbench, easy to use and comfortable. (selected)

Installation data:

Dimensions (excluding the rack) 1660mm (length) *746mm (width) *1165mm (height)

                                  (1664mm (length) *746mm (width) *1148mm (height))

Use environment:

Working temperature/humidity 0℃～45℃／20%～95% (non-condensing)

Storage temperature/humidity -20℃～60℃／20%～95% (non-condensing)

Working voltage 220VAC(±10%) 50±3HZ

Power loss 0.5KW

Noise level 55dB (A)
