一、路障机产品介绍
1、路障机主要功能是控制道路车辆通行，威慑和和阻止车辆强行通过。我司的该款路障机可以与道闸控制系统等配套使用，可以与我司的车底扫描和车底监控系统联动，也可以单独使用；
2、该款路障机是专门为监狱、看守所和戒毒所等监管场所量身打造的产品，具有很高的实用性、可靠性及安全性；该款路障机操作、保养维护十分简单，非常耐用，投放市场以来收到客户的普遍好评。

A .Roadblock machine products introduction

1, the main function of the barricade machine is to control the road vehicle traffic, deter and prevent vehicles from forcing through. Our roadblock machine can be used with the road gate control system, can be linked with our undercarriage scanning and undercarriage monitoring system, or can be used alone;

2、The barricade machine is specially designed for prisons, detention centers, drug rehabilitation centers and other places of supervision, with high practicality, reliability and safety; the operation, maintenance and maintenance of the barricade machine is very simple and durable, and has received universal praise from customers since it was put on the market.

路障专用潜水型车道全景AI侦测分析摄像机模块

路障应配置潜水型高清网络智能摄像机，可对控制区域进行人像识别与车辆防冲越侦测，自动报警联动输入输出控制。

具体要求：分辨率不低于1920×1080 @ 25 fps,在该分辨率下可输出实时图像；

码流平滑设置，适应不同场景下对图像质量、流畅性的不同要求；

高效红外灯,使用寿命长,照射距离不低于10-30米；

可防止夜间红外过曝；实现真正的日夜监控；；

可支持3D数字降噪,支持120dB超宽动态；

可支持三码流,支持手机监控；

可支持,背光补偿,自动电子快门功能,适应不同监控环境；

可支持多种智能报警；

可支持不少于1对报警输入/输出(-S)；

可支持智能后检索，配合NVR支持事件的二次检索分析；

可适应光线较暗或无光照环境且要求高清画质的场所，适合路障机使用的光线暗、逆光环境。

可进行越界侦测,区域入侵侦测,场景变更侦测,人脸侦测,非法停车侦测,人员聚集侦测,徘徊侦测,快速移动侦测,进入区域侦测,离开区域侦测,动态分析,遮挡报警,网线断等智能分析功能

二、技术参数
路障机由主机架、液压站、电控等三部分组成，可根据客户的需求定制。

1、系统控制：机电液压一体化驱动；采用高品质PLC控制，并配备LCD屏控制，系统运行性能稳定可靠，提供RS485或网口便于集成；

2、通过压力：可通行整车120吨以上货车；

3、供电电源：380V（控制电压24V）；

4、系统动力功率(w)：3.75KW/5.5KW；

5、上升时间：≤1-3S左右（可调）；

6、下降时间：≤1-3S左右（可调）；

7、工作温度：-50℃～+75℃（适合）；

8、存储环境：-50℃~75℃, 防雨防潮防尘；

9、材质：A3

10、防护等级：IP68；

11、拦截宽度：2500\3000\3500\4000\4500\5000\5500\6000mm多款型号(也可现场定制宽度）；升起高度：600/800(可按实际要求订做)。带实心钢尖刺；颜色：黄、黑双色；

12、举升力: 不低于20T；且带双向缓冲升降设施，确定系统长期高稳定运行；

13、路障机中间配全景防水型高清隐蔽式数字监控，并可智能防越线侦测报警，联动警报；

14、工作环境: 全天候；

15、保护功能：可与检测探头、感应线圈等连接，具有防误弹起；

16、警示方式:自动或遥控闪烁灯光警示；

17、升降控制:可遥控路障机上升、下降、停止、警示灯闪烁，，配置露天室外接收天线；

18、扇形区警示灯： 高亮警示闪灯；

19、路障机加架结构坚固耐用，尤其扇形承撞区要有多重横竖向支撑，可承载负荷大，升降动作平稳，噪声低；所有毛尖倒刺均应采用实心钢棒一次性机加工形成，具备锋锐的威慑力；

Second, the technical parameters

Barricade machine consists of three parts: main frame, hydraulic station, electric control, etc., which can be customized according to customer's needs.

1、System control: electromechanical hydraulic integrated drive; high-quality PLC control, and equipped with LCD screen control, stable and reliable system performance, provide RS485 or network port for easy integration;

2、through the pressure: can pass the whole 120 tons or more trucks;

3、Power supply: 380V (control voltage 24V);

4、System power (w): 3.75KW/5.5KW;

5、rise time: ≤ 1-3S or so (adjustable);

6、down time: ≤ 1-3S or so (adjustable);

7、Operating temperature: -50℃～+75℃(suitable);

8、storage environment: -50 ℃ ~ 75 ℃, rain, moisture and dust;

9、Material: A3

10、Protection grade: IP68;

11、Intercepting width: 2500\3000\3500\4000\4500\5000\5500\6000mm various models (also can be customized width on site); lifting height: 600/800 (can be customized according to actual requirements). With solid steel spikes; color: yellow, black two-color;

12、lifting force: not less than 20T; and with two-way buffer lifting facilities, to determine the long-term high and stable operation of the system;

13、barricade machine center with panoramic waterproof high-definition hidden digital monitoring, and can be intelligent anti-crossing detection alarm, linkage alarm;

14、Working environment: all-weather;

15、Protection function: can be connected with detection probes, induction coils, etc., with anti-false pop-up;

16、warning mode: automatic or remote control flashing light warning;

17、lift control: can be remote control barricade machine rising, falling, stopping, warning lights flashing, configure open-air outdoor receiving antenna;

18、sector warning lights: bright warning flashing lights;

19、the barricade machine plus frame structure is rugged, especially fan-shaped collision zone to have multiple horizontal and vertical support, can carry a large load, lifting and lowering action is smooth, low noise; all the burrs should be used solid steel bar one-time machined to form, with a sharp deterrent;

三、我司路障机产品特点：

1、路障机中间配全景防水型高清隐蔽式数字监控，可智能防越线侦测报警，联动警报；

2、结构坚固耐用，承载负荷大，动作平稳，噪声低。
3、采取PLC控制，系统运行性能稳定可靠，便于集成。
4、路障机与道闸等其它设备进行联动控制，也可以与其他控制设备组合，实现自动控制。
5、在停电的情况下或出现故障时，如路障机处于升起状态需要下降时，可以通过手动操作将升起的路障机盖板回落到水平位置以让车辆通行。
6、采用低压液压驱动技术，整个系统安全性高，可靠稳定。
7、遥控装置：通过无线遥控的方式，可在控制器周围100米左右范围内，遥控路障的升降。

C.Our barricade machine product characteristics:

1, the middle of the barricade machine with panoramic waterproof high-definition hidden digital monitoring, can be intelligent anti-crossing detection alarm, linkage alarm;

2, the structure is rugged and durable, carrying a large load, smooth action, low noise.

3, take PLC control, system operation performance is stable and reliable, easy to integrate.

4、Barricade machine and road gates and other equipment for linkage control, can also be combined with other control equipment to achieve automatic control.

5, in the case of power failure or failure, such as the barricade machine in the raised state needs to be lowered, can be manually operated to raise the barricade machine cover back down to the horizontal position in order to allow vehicles to pass.

6, the use of low-pressure hydraulic drive technology, the whole system is safe, reliable and stable.

7, remote control device: through the wireless remote control, can be in the controller around the range of about 100 meters, remote control of the barricade lift.
