特级反恐防冲撞 智慧阻车液压翻板路障机Special anti-terrorism anti-ramming Intelligent blocking hydraulic flap barricade machine

一、路障机产品(FK16-J4000型)介绍1、路障机主要功能是控制道路车辆通行,威慑和和阻止车辆强行通过。我司的该款路障机可以与道闸控制系统等配套使用,可以与我司的车底扫描和车底监控系统联动,也可以单独使用;2、该款路障机是专门为监狱、看守所和戒毒所等监管场所量身打造的产品,具有很高的实用性、可靠性及安

在线订购

一、路障机产品介绍

1、该款路障机拦截高度为800,相较传统路障机600mm的高度,拦截范围更高,拦截效果更强,有效控制道路车辆通行,威慑和和阻止车辆强行通过

2、我司的该款路障机可以与道闸控制系统等配套使用,可以与我司的车底扫描和车底监控系统联动,也可以单独使用;
3、该款路障机是专门为监狱、看守所和戒毒所等监管场所量身打造的产品,具有很高的实用性、可靠性及安全性;该款路障机操作、保养维护十分简单,非常耐用,投放市场以来收到客户的普遍好评。

1, the section of the barricade machine interceptor height of 800, compared with the traditional barricade machine 600mm height, intercepting a higher range, intercepting the effect is stronger, effective control of the road vehicle traffic, deterrence and to prevent the vehicle force through

2, the Division I of the section of the barricade machine can be used in conjunction with the road gate control system, etc., can be linked with the Division I of the undercarriage scanning and undercarriage monitoring system, can also be used alone;

3, the barricade machine is specifically for prisons, detention centers and drug rehabilitation centers and other places of supervision tailor-made products, has a high degree of practicality, reliability and safety; the barricade machine operation, maintenance and repair is very simple, very durable, since the market has received general praise from customers.


二、索安AI智能路障系统的特色
1、智能路障系统是利用AI技术进行雷达侦测与高清成像分析并人脸识别与车牌识别,通过与后台公安人员与车辆的黑名单数据库比对,自动侦测到危险人员驾驶的非法车辆,系统会迅速联动升起路障机,强行阻止拟强行冲撞车辆,同时联动关闭所有主要出入口通道门禁,并进行高音广播警报信息,自动呼叫附近的警力进行支援。
2、通过智能路障可以清晰地看到车辆的行驶速度是否安全低速、行驶的方向与运动轨迹、可能的目标方向,车辆驾乘人员的人像比对并进行大数据挖掘与分析,超前预判危险,给警卫及相关部门有一定时间迅速启动应急预案。
3、通过智能路障进行车辆与人员的有序通行的秩序控制,同时对进出人员与车辆进行信息记载,以便于数据信息保全。

1, The intelligent roadblock system is using AI technology for radar detection and high-definition imaging analysis and face recognition and license plate recognition. By comparing with the blacklist database of public security personnel and vehicles in the background, the system will automatically detect illegal vehicles driven by dangerous people, and the system will quickly link up to raise the roadblock machine to forcibly stop the proposed forcible ramming vehicles, and at the same time link up to close all major entrance/exit channel gates and make high pitch broadcast alarm information and automatically call the nearby police force for support.

2, The intelligent roadblock can clearly see whether the speed of the vehicle is safe and low, the direction of travel and trajectory, the possible target direction, the portrait comparison of the vehicle driver and occupants and conduct big data mining and analysis to pre-empt the danger and give the guards and related departments some time to quickly start the emergency plan.

3, The orderly passage of vehicles and personnel is controlled through intelligent roadblocks, while information is recorded on incoming and outgoing personnel and vehicles to facilitate data and information preservation.

三、液压路障机技术参数

路障机由路障装置、液压传动装置、自动检控装置三部分组成,可根据客户的需求定制。

1、系统控制:PLC智能驱动电动液压
2、通过压力:可通行整车120吨以下货柜车。
3、供电电源:三相AC380V(控制电压24V)。
4、系统动力功率(w):不低于3.75KW。
5、上升时间:1-3S(可调)。
6、下降时间:1-3S(可调)。
7、工作温度:-35℃~75℃(适合)。
8、存储环境:-35℃~75℃, 防雨防潮防尘。
9、材质:A3钢20mm、25mm厚,喷防锈底漆。
10、路障机内部器件防护等级:IP68。
11、颜色:多种颜色(可选)
12、机体规格:(3000mm/3500mm/4000mm/4500mm/5000mm/5500mm)×宽995×高760mm,升起高度:800mm(可按实际要求订做)

1, System control: PLC intelligent drive electric hydraulic

2, Passing pressure: it can pass the whole truck with less than 120 tons of container truck.

3, Power supply: three-phase AC380V (control voltage 24V)

4, System power power(w): not less than 3.75KW

5, Rise time: 1-3S (adjustable)

6, Down time: 1-3S (adjustable)

7, Working temperature: -35℃~75℃ (suitable)

8, Storage environment: -35℃~75℃, rain-proof, moisture-proof and dust-proof.

9, Material: A3 steel 20mm, 25mm thick, sprayed with anti-rust primer.

10, Protection level of internal devices of barricade machine: IP68.

11, Color: various colours (optional)

12, Body specification: (3000mm/3500mm/4000mm/4500mm/5000mm/5500mm)×width 995×height 760mm, lifting height: 800mm (can be customized according to actual requirements)无锡公安局1.jpg

四、我司路障机产品特点:

1、结构坚固耐用,承载负荷大,动作平稳,噪声低。
2、采取PLC控制,系统运行性能稳定可靠,便于集成。
3、路障机与道闸等其它设备进行联动控制,也可以与其他控制设备组合,实现自动控制。
4、在停电的情况下或出现故障时,如路障机处于升起状态需要下降时,可以通过手动操作将升起的路障机盖板回落到水平位置以让车辆通行。
5、采用低压液压驱动技术,整个系统安全性高,可靠稳定。
6、遥控装置:通过无线遥控的方式,刷卡方式,手机远程遥控,车底扫描软件控制、电脑端远程可视控制系统(指挥中心终端远程控制系统,支持互联网通讯、WIFI、3GPRS等控制方式。

1, Strong and durable structure, large load-bearing, smooth action and low noise.

2, Adopt PLC control, system operation performance is stable and reliable, easy to integrate.

3, The barricade machine is linked and controlled with other equipment such as road gates, and can also be combined with other control equipment to achieve automatic control.

4, In case of power failure or malfunction, if the barricade machine is in a raised state and needs to be lowered, the raised barricade machine cover can be manually operated to bring it back down to a horizontal position to allow vehicles to pass.

5, Adopting low pressure hydraulic drive technology, the whole system is safe, reliable and stable.

6, Remote control device: through wireless remote control, card swipe, mobile phone remote control, undercar scanning software control, computer remote visual control system (command centre terminal remote control system, support Internet communication, WIFI, 3GPRS and other control methods.


五、智能配置:

1、(可选配)具有智能雷达测速识别功能,系统采用智能雷达来侦测来往车辆的行驶速度。雷达侦测到有车辆开来,如果速度低速且不断减速,结合许可车辆授权情况(即白名单)可视为安全,仅语音提示警卫去注意门口有车来,但不去联动报警与紧急升起路障机。如果外来车辆呈快速且急加速,视为危险行为有冲关可能好,则急促的警报响起,并迅速升起路障机,并抓紧视拍与录像;简单来说,当进入道口的车辆未经安检人员作出放行指令前试图强行通过时,或系统黑名单内的车辆车牌号码,自动弹起防撞墙进行拦截。
2、(可选配)能自动侦测车速,实时电脑软件显示车辆速度、危险等级,路障机上高清监控摄像机传送的图像显示在软件中,危险情况联动自动语音报警播放;
3、(可选配)路障应配置潜水型高清网络智能摄像机,可对控制区域进行人像识别与车辆防冲越侦测,自动报警联动输入输出控制。
4、(可选配)保护功能:可与检测探头、感应线圈等连接,具有防误弹起功能。
5、(可选配)具有与道闸、雷达测速、电动伸缩门等设备的联动功能,具有智能预警发现紧急危险驾驶行为,冲卡时自动弹起,自动拍摄冲卡车辆的车牌号并识别,车辆与人像抓拍上报至指挥中心。
6、(可选配)温控功能:高寒地带可配具有自动加热恒温系统,使系统能在低温雨雪天气状况下正常运行。

1,  (optional) with intelligent radar speed recognition function, the system uses intelligent radar to detect the driving speed of incoming vehicles. Radar detects a vehicle driving, if the speed is low and constantly decelerating, combined with the permit vehicle authorization situation (i.e. white list) can be regarded as safe, only voice prompts the guard to pay attention to the door with a car coming, but not to linkage alarm and emergency raise the barricade machine. If the foreign vehicle is fast and rapid acceleration, as a dangerous behaviour has a good possibility of rushing through the gate, then a sharp alarm sounds, and quickly raise the barricade machine, and grab the video and video; in short, when the vehicle entering the crossing tries to force through without the security personnel to make release instructions, or the vehicle number plate number in the system blacklist, automatically pop up the anti-collision wall to intercept.

2,  (optional) can automatically detect the speed of the vehicle, real-time computer software display vehicle speed, danger level, high-definition surveillance camera on the barricade machine transmitted image displayed in the software, dangerous situation linked automatic voice alarm playback;

3,  (Optional) The barricade should be equipped with a submersible HD network intelligent camera, which can perform portrait recognition and vehicle anti-rush detection on the control area, and automatic alarm linkage input and output control.

4, (Optional)Protection function: It can be connected with detection probe, induction coil, etc., with anti-false pop-up function.

5, (Optional)with linkage function with road gates, radar speed detection, electric expansion gates and other equipment, with intelligent warning to find emergency dangerous driving behaviour, automatic pop-up when punching, automatic shooting of the license plate number of the punching vehicle and identification, vehicle and portrait capture reported to the command centre.

6,  (optional) temperature control function: alpine zone can be equipped with automatic heating thermostat system, so that the system can operate normally in low temperature rain and snow weather conditions.
